HE9180 Powerful Excavator: 0.8m³ Bucket, 111KW Engine

Excavators

HE9180 Excavator – Power and Versatility for Heavy-Duty Tasks

Meet the HE9180 Excavator, engineered for high performance and versatility in demanding environments. Equipped with a 111 KW engine and a bucket capacity of 0.8 m³, this excavator is designed to handle heavy-duty excavation and material handling with ease. Key features include a maximum digging depth of 5350 mm and a digging radius of 8480 mm, offering impressive reach and efficiency for large-scale projects.

The HE9180 provides a swing speed of up to 12 RPM and a gradeability of 25°, ensuring smooth operation on various terrains. With dimensions of 8050 x 2595 x 3255 mm and a minimum swing radius of 2720 mm, the HE9180 is ideal for large projects requiring both power and precision.

Bucket Capacity

0.8 m³

Engine Model

B5.9CS4-15OC

Power

111 KW

Cabin Height

3150 mm

Inquire Now

Product Description Specifications: Bucket Capacity: 0.8 m³ Swing Speed: 0-12 RPM Gradeability: 25° Max. Bucket Digging Force: 100 KN Max. Arm Digging Force: 70 KN Engine Model: B5.9CS4-15OC Power/Revolution Speed: 111 KW/2200 RPM Tire Model: 10.00-20 System Pressure: 32 MPa Machine Size: Dimension (LWH): 8050*2595*3255 mm Cabin Height: 3150 mm Axle Base: 2600 mm Wheel (Track) Distance: 1955 mm Minimum Ground Clearance: 430 mm Tail Swing Radius: 2365 mm Working Range: Max. Dozer Blade Cutting Distance: 85 mm Max. Digging Height: 9200 mm Max. Dumping Height: 6620 mm Max. Digging Depth: 5350 mm Max. Vertical Digging Depth: 4850 mm Max. Digging Radius: 8480 mm Min. Swing Radius: 2720 mm Max. Dozer Blade Lifting Distance: 420 mm
